Responder 24 Electromagnetic Door Closer

Rutland RESPONDER24 Electromagnetic Door Closer universal, it can be fitted on push, pull, left or right side, in hold-open or swing-free mode – making it super easy to specify & order.

Successfully third party tested to BS EN1154 & CE marked to power size 4.

Features:

  • Fixed power  EN4 – does doors up to 80kg & 1100mm wide
  • Hold-open & swing free in one box
    • Hold-open angle – 90° – 120°
  • The electromagnet is activated by the fire alarm system, releasing instantly in the event of a fire alarm activation
  • Available in Silver, Satin Nickel, Polished Nickel, Polished Brass & Antique Brass for next day delivery
  • Fire tested to BS EN 1634-1
  • BS EN 1154 & BS EN 1155 tested
  • 5 year guarantee

Certification & Compliance

  • EPD VERIFIED as per ISO 14025 and EN 15804+A2

Designed for use with:

  • PSU.1224.9 – Power Supply Unit
  • Corridor doors use Hold-open mode
  • Living and Bedroom doors use Swing-free mode
  • Voltage Output : 24v DC
    It is recommended that for each E-Mag Door Closer (Responder 24 and FireTrak 114 & FireTrak 115) that a 1A Power Supply Unit is specified, however if fitting to double doors then a 2A Power Supply Unit can be used to operate the two E-Mag Closers.
  • For push-side application (Parallel arm/Fig 66), depending on location of switch box e.g. frame or wall mounting, the extended loop cable DL.184.600 may assist installation.
Product features:

Max Door Weight 80kg

Max Door Width 1100mm

Power Size EN4

Opening Angle 150°

Universal Application

Adjustable Latch Speed

Adjustable Closing Speed

Rut Lock

Third Party Certification

Guarantee

24V DC

Options:

+ IP.RESPONDERM needed for un-insulated fire doors

Available finishes:

Silver (SE)

Satin Nickel Plate (SNP)

Polished Nickel Plate (PNP)

Polished Brass (PVD)

Antique Brass (AB)
