TS.9206 Door Closer
TS.9206 is ideal for heavy usage and is power adjustable by spring size 3-6. This closer has a unique slimline appearance and comes with back check and delayed action as standard.
Features:
- Suitable for use on doors up to 1400mm wide
- Max door weight <120kg
- Power adjustment by spring
- Opening angle 180º
- Standard finishes – corrosion resistance – Grade 3: High Corrosion resistance
- MARINE 316 – Grade 5: Exceptionally high corrosion resistance
- 35 Year Guarantee
- Available in 4 different finishes for next day delivery
Certification & Compliance Summary
- EPD VERIFIED as per ISO 14025 and EN 15804+A2
- BS EN 1154
- BS EN 1634
- BS EN 1670 – Grade 5
- UKCA
- CE
- See Downloads section below for full details.
Product features:
Max Door Weight up to 120kg
Max Door Width up to 1400mm
Power Size EN2-6
Opening Angle 180°
Universal Application
Adjustable Latch Speed
Adjustable Closing Speed
Adjustable Delayed Action
Rut Lock
Third Party Certification
9206DABCCPR171218
Guarantee
Adjustable Back Check
Options:
+ Hold open arm-set (not suitable for fire doors)
+ IP.96M needed for un-insulated steel fire doors
Available finishes:
Silver (SE)
Satin Nickel Plate (SNP)
Polished Nickel Plate (PNP)
Polished Brass (PVD)
Satin Stainless Steel (SSS)
Polished Stainless (PSS)
Black (BK)
Marine 316 (M)
Downloads
Specification & Data Sheets
Certification & Compliance
Fitting Instructions & BIM downloads
